Axpert KING 3KVA - Inverter Family; Overview the Inverter

SERVICE MANUAL
3KVA/5KVA-230V
4
V201703A
1.3 Inverter family
This service manual includes different models of the inverter, the table as below contains some important
parameters with different models.
These models names are only neutral names; please match the real model name of your inverter to the model
name in the table by comparing the typical characteristics.
Model name
Power rating
Solar charger
type
Solar charger
number
Off-grid/Hybrid
3KVA
3KVA/3KW
MPPT
1
Off-grid
5KVA
5KVA/5KW
MPPT
1
Off-grid
Note: Main board of 3KVA model is 16-501021-XXG, main board of 5KVA model is 16-501016-XXG.
1.4 Overview the inverter
COMM board
16-501026-XXG
IND board
16-501058-XXG
Main board
16-501021-XXG
CNTL board
16-501015-XXG
MPPT board
16-500689-XXG
CAP board
16-000259-XXG
