24
CONNECTING DIAGRAM 1 x PRE-OUT
F F
PLEASE NOTE!
• Min. Impedance for all speaker
is 2 Ohms!
• SUB-input signal should be a
fullrange signal!
Any pre-filtered lowpass signal
from head-unit will always shift
lowpass frequency on amplifier
downwards!
• A main fuse 60 A must be
installed 30 cm within of car
battery!
