6.2 Adjusting aids for Integer Parameters
With the potentiometers also integer values are set. To support this procedure the instrument
offers two adjusting aids, which both work at the same time:
1. Display:
-
1 1
-
1
-
2 2
-
2
-
3 3
-
3
-
4 4 etc.
The value is correctly adjusted, if no dash is represented.
2. Valve LED row: Cycle adjustment: LED line flashes or lights up
Valve adjustment: max. 2 individual LEDs flash or light up
Cycle Adjustment
Display LED-row (Valves)
Valve Adjustment
Display LED-row (Valves)
-
2
flashing
-
2
-
3
flashing
-
3
3 flashing 5 sec
3
-
3 flashing
-
3
-
4
flashing
-
4
flashing
flashing
flashing 5 sec
flashing
flashing
During the adjustment the cleaning process is not interrupted: the cleaning pulse is also
displayed. The representation of a valve error is suppressed however during the adjustment.
