12 - SPARE PARTS
The spare parts indicated in Fig. 3, 4, 5 and 6 that is:
A: Pipetting pushbutton A1: Pushbutton A2: Knob
B: Adjustment knob
C: Shaft
D: Ejector
F: Shaft nut
G: Piston assembly
H: Spacer
I: O-ring
J: Seal
K: Calibration key
L: Filter
M: Ejector cap
N: Ejector pushbutton
P: Identification ring
S: Locking ring
can be ordered from your AXYPET representative (type
of pipette and name of the part for this pipette should be
specified).
To find your nearest service center and for technical
support, visit http://www.axygen.com/axypet
Warning: The replacement of the piston requires
a calibration procedure to be carried out, as
described in section 8.
ENGLISH
All rights reserved. Product described in this manual is subject to availability
and technical modification. Errors excepted.
AXYGEN reserves the right to improve, enhance or otherwise modify its
products without prior notification.
