 Specications
z Basic specications
Item Rating
Power supply Input voltage 100–240 V AC (264 V AC max.)
Input frequency 50/60 Hz ± 3 Hz
Power consumption Model RJ -1101W16 00 13 VA max.
Model RJ-1102W1600 14 VA max.
Model RJ-1103W0400 16 VA max.
Inrush current 20 A max. (100 V AC)
40 A max. (240 V AC)
Leakage current 0.2 mA max. (100 V AC)
0.5 mA max. (240 V AC)
Insulation resistance Between power terminals together and ground terminal:
100 MΩ or higher (500 V DC)
CPU 32-bit
Memory device Flash ROM 512 kB, SRAM 96 kB
Communication Ethernet Number of ports 2
Port function Auto recognition of MDI/MDI-X
Communication
method
Proprietary protocol
Communication
speed
100 Mbps
Major material Case, cover Modied PPE resin
DIN holder POM resin
Weight 0.65 kg
Environment Operating
conditions
Ambient temperature 0–50 °C
Ambient humidity 10–90 % RH (without condensation)
Altitude 2,000 m max.
Vibration 5.9 m/s
2
max. (at 10–150 Hz)
Transportation/
storage
conditions
Ambient temperature -20–60 °C
Ambient humidity 5–95 % RH (without condensation)
Vibration (storage) 5.9 m/s
2
max. (at 10–150 Hz)
Vibration
(transportation)
9.8 m/s
2
max. (at 10–150 Hz)
Others • No corrosive gas should be detected.
• The product must not be exposed to direct sunlight.
• Do not let the product get wet.
Installation location In the control panel
Installation method Installed on a DIN rail or with screws
