Aztech GR7000 User Manual

User Manual
Page 6 of 47
Device Overview
Front Panel
LABEL STATE DESCRIPTION
POWER
On – Solid Green
On – Solid Red
Off
Device is powered ON
Device failure
Device is powered OFF
WAN
On – Solid Green
On – Blinking Green
Off
WAN port is connected
Indicates WAN activity
WAN port is not connected
ETHERNET LAN
On – Solid Green
On – Blinking Green
Off
Ethernet device is connected
Indicates LAN activity
No Ethernet device connected
USB HOST
On – Solid Green
On – Blinking Green
Off
USB device is connected
Indicates USB activity
No USB device connected
WIRELESS
On – Solid Green
On – Blinking Green
Off
Wireless interface is UP
Indicates wireless activity
Wireless interface is DOWN
INTERNET
On – Solid Green
On – Blinking Green
On – Red
Off
Internet connection is UP
Indicates Internet activity
PPPoE authentication failed
Internet connection is DOWN
WPS
On – Solid Green
On – Blinking Green
Off
WPS association is successful
WPS authentication on going
WPS disabled

Aztech GR7000 Specifications

General

Port forwarding	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Routing protocols	RIP-1, RIP-2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
3G	No
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
Wi-Fi band	-
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Maximum outdoor range	300 m
WLAN data transfer rate (max)	600 Mbit/s
Transmit power	0 dBmW
Product type	Tabletop router
Product color	White
WAN connection type	RJ-45
Output voltage	12 V
Power source type	DC
Number of products included	1 pc(s)
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Minimum processor	233 MHz
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	157 mm
Width	200 mm
Height	32 mm
Weight	440 g
