Top Panel
Back Panel
LABEL DESCRIPTION
RESET
Press the Reset button for 5 seconds to restore the device to
default factory settings
DC IN Connect to a 12V DC Power Adapter
USB PORT 1 Connect to a USB storage device or USB printer
USB PORT 2 Connect to a USB storage device or USB printer
ETHERNET LAN 1-4 Connect to computers/Ethernet devices
ETHERNET WAN Connect to a Cable/ADSL modem or ONT
