Panel layout
INPUT Hpf (40 ~500 hz) High Pass crossover
RCA signal input for left & right channel. (CH1 ~ CH4) 41 click potentiometer with ACCU8 frequency tuning.
A minimum of 0.2V input signal is required for correct Each click corresponds to a selected frequency.
operation. If the multiplier is used, the frequency on the clicks
increases by a factor of 10.
output
RCA signal output to external devices, ampliers, etc. LPF (20 Hz ~ 1 Khz) Low pass crossover
41 click potentiometer with ACCU8 frequency tuning.
Each click corresponds to a selected frequency.
Gain
Adjusts signal input voltage from the input source to Hpf - full lpf
match the ampliers input stage. 0.2V ~ 5V is the operational Crossover selection switch, when placed in full, no crossover
voltage. Voltages beyond may cause errors or damages to is applied. The frequency range of the amplier is fullrange.
to the input section..
status led
x10 (frequency multiplier) Power lit = amplier on, normal operation. Clip lit or ashing
When selected the High Pass crossovers frequency range is = signal output to the speakers is not clean. Distortion is
multiplied by a factor of 10. detected. Protect = amplier has shut down operation
.
Caused by error, user failure, thermal or damage.
high inputs
High level input from loudspeaker wires, this option is only
preferred if there is no RCA connection available. This will
provide a signal input from the oem wire harness in the car.
