11
accu8 crossover & boost
.
The low pass crossover is 18 dB / oct. Setting it at 80 Hz will then have the signal cut off with 18rrrr dB at 40 Hz (1 octave).
To ensure accuracy for the individual crossover frequency the pot feature 41 clicks, each with a corresponding frequency.
The same is valid for the bass boost settings, which also features 41 clicks. We call this feature for ACCU8.
CLick settings for LPF - Bass Boost
LPF Boost LPF Boost LPF Boost
1. 33 Hz - 0 dB 15. 61 Hz - 8,50 dB 29. 160 Hz - 8,90 dB
2. 34 Hz - 0,30 dB 16. 68 Hz - 8,60 dB 30. 170 Hz - 8,90 dB
3. 34 Hz - 0,40 dB 17. 76 Hz - 8,70 dB 31. 181 Hz - 8,90 dB
4. 35 Hz - 0,50 dB 18. 86 Hz - 8,70 dB 32. 185 Hz - 8,90 dB
5. 35 Hz - 0,75 dB 19. 100 Hz - 8,80 dB 33. 190 Hz - 8,90 dB
6. 36 Hz - 3,50 dB 20. 111 Hz - 8,80 dB 34. 195 Hz - 8,90 dB
7. 36 Hz - 5,60 dB 21. 116 Hz - 8,80 dB 35. 200 Hz - 9,00 dB
8. 39 Hz - 6,70 dB 22. 120 Hz - 8,80 dB 36. 203 Hz - 9,00 dB
9. 41 Hz - 7,40 dB 23. 125 Hz - 8,80 dB 37. 207 Hz - 9,00 dB
10. 43 Hz - 7,80 dB 24. 130 Hz - 8,90 dB 38. 210 Hz - 9,00 dB
11. 46 Hz - 8,00 dB 25. 135 Hz - 8,90 dB 39. 230 Hz - 9,00 dB
12. 50 Hz - 8,20 dB 26. 140 Hz - 8,90 dB 40. 240 Hz - 9,00 dB 240 Hz - 900 dB
13. 55 Hz - 8,40 dB 27. 144 Hz - 8,90 dB 41. 250 Hz - 9,00 dB
14. 57 Hz - 8,40 dB 28. 151 Hz - 8,90 dB
Low pass, Bass Boost
