▪ design specifications
model: zero 15 - vegvisir
circuit configuration: hi-ef class d
frequency response: 10 hz-300 hz
signal to Noise Ratio: >95 db
input sensitivity: 5 v-0.2 v
crossover circuit: 24 db/oct
low pass crossover: 35 hz-250 hz
subsonic crossover: 10 Hz - 50 hz
phase: 0 ~ 180°
damping factor: >400
level control
• with clip/volt/temp: INCLUDED
power terminal gauge: 4 x 0 gauge / 67 mm
2
fuse rating: 1200 A
dimensions metric: 996
x 315 x 75 mm
imperial: 39.25”
x 12.4“ x 2.95”
continious output power (RMS) @ 14.4V <1% THD
descriptions of specifications
* full output power according to the spec is based on a sufficient electrical supply system. if your system is inadequate, the efficiency of the amplifier decreases,
hurting the performance!
operation below minimum impedance will stress the amplifier & void the warranty. Excessive heat will occur, causing the amplifier to go into thermal protection.
The circuit may sustain permanent damage and protection lights won’t turn off or flash sequentially.
Operational voltage is from 9v to 17.5v
Protection may also be caused by the following
• input voltage from headunit being too high / low / power supply voltage too high / low.
• speaker overload
• short circuit
*full output power according to the spec is based on a sufficient electrical supply system. if your system is inadequate, the efficiency of the amplifier decreases,
hurting the performance!
MININUM BATTERY REQUIREMENTS AGM LITHIUM 6C
zero15 - vegvisir 6x 125 AH / 1250 CCA 200 AH
the list above describes the additional dedicated battery supply for the amplifier. The oem battery does not count as a part of it.
3
measured @ <1% thd (40 hz) using audio precision*
12.6 v < 1% tHD 14.4 v < 1% THD 16 v < 1% thd
OUTPUT POWER @ 4 Ω: 4000 W 5500 W 6500 w
OUTPUT POWER @ 2 Ω: 7500 W 9500 W 11000 w
OUTPUT Power @ 1 Ω: 12000 W 15000 W 16000 w
Dynamic rated power (music / Spl Burp)
>24000 W @ 11.5 V
