-69-
Main PC board (BL6800 only)
CN8 Inlet (Power supply input)
CN7 Power supply switch
CN6 SS-VR board
Sensor board
LJ1 FG Line
CN4
Foot controller
j
ack
CN3
Bobbin winder
switch
CN2
Reverse sewing
switch
CN1 Lamp
CN9 Motor
