Baby Lock BL9 - Attaching and Removing the Presser Foot

10
w
q
q
w
Presser Foot Lifter
The presser foot lifter raises and lowers your presser
foot.
You can raise it about 0.6 cm (1/4˝) higher than the
normal up position for easy removal of the presser foot
or to help you to place heavy fabric under the foot.
q Normal up position
w Highest position
CAUTION:
Turn off the power switch when changing a presser
foot.
To Attach and Remove the Presser Foot
To remove
Turn the handwheel toward you to raise the needle to
its highest position.
Raise the presser foot.
Press the lever on the back of the foot holder.
The presser foot will drop off.
To attach
Place the presser foot so the pin on the foot lies just
under the groove of the foot holder.
Lower the foot holder to lock the foot in place.
q Pin
w Groove
