10. Troubleshooting
Possible cause(s)
Problem
• The power adapters may not be properly connected.
• Ensure that the Baby and Parent Units are ON.
• Make sure the Baby Unit and Parent Unit are not far away
from each other.
• Baby Unit and Parent Unit may not be properly paired.
Follow PAIRING instructions.
No reception on the Parent Unit
• Move the Baby Unit closer to Parent Unit.
• The Baby or Parent Units may be too close to metal
objects.
• Other electronic devices may be interfering with the signal.
• The battery power may be too low.
Interference or poor reception
• Restart the Baby Unit (pull out the power adapter from the
wall outlet, wait for approx. 5 seconds and plug it back in).
• Reset the Parent unit by opening the battery compart ment
and disconnecting the battery.
Wait for 30 seconds and then reconnect the battery.
Image frozen on the Parent Unit
11. Technical Data
• 2.4GHz FHSSFrequency
• Up to 960 feet (open space)Operating Range
• Input: 240-100VAC 60 / 50Hz, 200mA Max;
• Output: 5V, 700mA;
Power Adapter
• 2.4” TFT LCD LCD Screen
• Model: YB 503450
• 3.7V, 950 mAh, 3.515Wh
Rechargeable battery
(pre-installed in Parent Unit)
• Approx. up to 10 hours (ECO on)Operating time with battery
fully charged (Parent Unit)
• 18dBm MaxTransimitting Power
• 1/6.5 “ Color CMOSImage sensor type
• 940nmIR LED Type
• Indoor use only; Temperature: 104-32 °F
• Humidity: 5% to 90% rh. (relative humidity)
Operation Environment
