5
Fig. 5
6
Fig. 6
L
H
5end (locking position).
M
L
H
Place the burner assembly (D) onto the table top panel (E) .
Attach two parts with 4 M4 x 25 bolts (BB), 4 D5 washers (EE).
The control panel on the burner assembly (D) should fit the
position on the front panel (G).
6
D
E
E
EE
BB
BB M4x25 Bolt 4Pcs
EE D5 Washer 4Pcs
G
ASSEMBLY INSTRUCTIONS
9
