Backyard Discovery 55006 - Page 53

STEP 23
ATTACH THE SHELF BUILT IN THE PREVIOUS STEP TO THE K9-3, K9-4,
AND K9-5 WALL BOARDS BY RESTING THE K3 BOARD ON TOP OF THE
OPENING AND FASTENING WITH HARDWARE SHOWN THROUGH PRE
DRILLED HOLES.
STEP 22
ATTACH H3 SHELF SUPPORTS TO K3 AND H1 BOARDS USING HARDWARE
AS SHOWN THROUGH PRE DRILLED HOLES.
H3 - SERVING BOARD SUPPORT - W101606
1"x3 3/8"x3 3/8" (24x86x86)
(2)
H1 - SERVING SHELF SUPPORT - W101604
1"x3 3/8"x30 3/4" (24x86x780)
(1)
K3 - SERVING BOARD - W101605
5/8"x5 1/4"x28 3/4" (16x134x729)
(1)
SCREW PFH
8x2
(4)
SCREW PFH
8x1 1/2
(9)
SCREW PFH
8x1 1/4
(22)
SCREW PFH 8x1 1/4
(22 PLCS)
K3
H3
H1
SCREW PFH 8x1 1/2
(9 PLCS)
SCREW PFH 8x2
(4 PLCS)
