Backyard Discovery OAKMONT - Page 35

STEP 7
F71 - STANDARD ANGLE BRACE - W100689
1 3/8"x2 3/8"x13" (36x60x330)
(1)
T-NUT 5/16 (1)
LAG SCREW
WH 5/16x2 1/2
(1)
WASHER
LOCK EXT
8x19
(2)
BOLT WH
5/16x2
(1)
SCREW PFH 8x2 1/2
(4 PLCS)
"A" REVISION TAG
(1 PLC)
SCREW PWH 8x5/8
(2 PLCS)
LAG SCREW WH 5/16x2 1/2
(1 PLC)
WASHER LOCK EXT 8x19
(2 PLCS)
BOLT WH 5/16x2
(1 PLC)
T-NUT 5/16
(1 PLC)
SCREW PWH
8x5/8
(2)
SCREW PFH
8x2 1/2
(4)
F71
H3
H3 - FLOOR JOIST - W4L04692
1"x3 3/8"x40 1/8" (24x86x1018)
(1)
SQ - "A" REVISION TAG - A100314
(1)
