Backyard Discovery Tucson 65411 - Page 15

Parts Identification
Wood Components
(NOT TO SCALE)
K2 - ARCHED WALL RAIL - W101531
5/8"x5 1/4"x34 7/8" (16x134x887)
(1)
K3 - ARCHED WALL RAIL - W101530
5/8"x5 1/4"x34 1/8" (16x134x868)
(1)
K4 - WALL RAIL - W101533
5/8"x5 1/4"x34 1/8" (16x134x868)
(1)
M1 - TARP SUPPORT - W101540
5/8"x3 3/8"x40" (16x86x1016)
(2)
M2 - FLOOR BOARD - W101525
5/8"x3 3/8"x36 3/4" (16x86x935)
(13)
M3 - TARP SUPPORT - W101539
5/8"x3 3/8"x36 3/4" (16x86x935)
(3)
M4 - FLOOR/TARP SUPPORT - W101541
5/8"x3 3/8"x34 7/8" (16x86x887)
(2)
M5 - WALL RAIL - W101522
5/8"x3 3/8"x34 7/8" (16x86x887)
(2)
M6 - WALL RAIL - W101523
5/8"x3 3/8"x34 7/8" (16x86x887)
(1)
M7 - FLOOR BOARD - W101524
5/8"x3 3/8"x32 1/8" (16x86x815)
(2)
