Backyard Discovery Tucson 65411 - Page 16

Parts Identification
Wood Components
(NOT TO SCALE)
M8 - PICNIC CLEAT - W101632
5/8"x3 3/8"x10 1/8" (16x86x258)
(1)
M9 - PICNIC CLEAT - W101633
5/8"x3 3/8"x6 3/4" (16x86x172)
(1)
M10 - WALL RAIL - W101621
5/8"x3 3/8"x6 1/4" (16x86x160)
(2)
M11 - WALL RAIL - W101527
5/8"x3 3/8"x4 3/4" (16x86x122)
(2)
M12 - WALL SLAT - W101536
5/8"x3 3/8"x25 1/4" (16x86x640)
(9)
M71 - ROCK BOARD - W100022
5/8"x3 3/8"x20 1/4" (16x86x514)
(6)
M72 - ROCK WALL SLAT - W100023
5/8"x3 3/8"x20 1/4" (16x86x514)
(2)
M77 - SLIDE BRACE - W100544
5/8"x3 3/8"x17 1/4" (16x86x438)
(1)
M78 - CENTER SLIDE BRACE - W100545
5/8"x3 3/8"x17 1/4" (16x86x438)
(2)
N1 - WALL RAIL - W101624
5/8"x1 1/8"x34 1/8" (16x30x868)
(1)
SB74 - SWING BEAM - W102304
2"x5 1/4"x89 1/2" (50x134x2274)
(1)
W71 - SWING BEAM SUPPORT - W102305
2"x3 3/8"x46 1/8" (50x86x1170)
(1)
