STEP 3
ATTACH (2) QZ TRIANGLE PLATES TO W71 SWING BEAM SUPPORT USING 1-3/4"
BOLTS, LOCK WASHER AND 7/8" BARREL NUT.
BOLT WH
5/16x1-3/4
WASHER
LOCK EXT
12x19
NUT BARREL
WH 5/16x7/8
SWING BEAM ASSEMBLY
SB74
W71
SB74
W71
QZ
