Backyard Discovery Weston 65113 - M10097 - Sheet 5

STEP 5
WASHER
LOCK EXT
8x19
(6)
T-NUT 5/16 (2)
LAG SCREW
WH 5/16x2
(6)
K2
M6
M6
T-NUT 5/16
(2 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
LAG SCREW WH 5/16x2
(2 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
LAG SCREW WH 5/16x2
(4 PLCS)
T-NUTS SHOULD FACE
TOWARD THE OUTSIDE
OF THE FORT.
K2 - ARCH BOARD - W103812
5
/8"x5 1/4"x30" (16x134x762)
(1)
M6 - FLOOR RAIL - W103806
5/8"x3 3/8"x30" (16x86x762)
(1)
