Backyard Discovery Weston 65113 - M10097 - Sheet 6

STEP 6
BOLT WH
5/16x1-1/2
(2)
WASHER
LOCK EXT
8x19
(4)
WASHER
LOCK EXT
12x19
(2)
NUT BARREL
WH 5/16x7/8
(2)
LAG SCREW
WH 5/16x2
(2)
NUT BARREL WH 5/16x7/8
(2 PLCS)
WASHER LOCK EXT 12x19
(2 PLCS)
BOLT WH 5/16x1-1/2
(2 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
LAG SCREW WH 5/16x2
(2 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
F71 - STANDARD ANGLE BRACE - W100689
1
3/8"x2 3/8"x13" (36x60x330)
(2)
