STEP 17
SCREW PFH 8x2
(4 PLCS)
SCREW PFH 8x2
(4 PLCS)
SCREW PFH
8x2
(8)
M10
M10
M10 - END TARP SUPPORT - W103817
5/8"x3 3/8"x31 7/8" (16x86x810)
(2)
45
