STEP 16
REFERENCE VIEW
SCREW PFH
8x1-1/8
(7)
SCREW PFH 8x1-1/8
(7 PLCS)
N1
FLUSH
N1 - WINDOW BOARD - W103828
5
/8"x2 3/8"x21 1/2" (16x60x546)
(1)
44
