Backyard 1705012 - Page 29

SLIDE ASSEMBLY
STEP 2
M78 - CENTER SLIDE BRACE - W100545
5/8"x3 3/8"x17 1/4" (16x86x438)
(2)
EK - SLIDE RAIL 8' GREEN RIGHT - A100054
(1)
EL - SLIDE RAIL 8' GREEN LEFT - A100055
(1)
SCREW PFH
8x2 1/2
(24)
TIP: A HELPER IS REQUIRED FOR THIS STEP.
NOTE:
MAKE CERTAIN
SUPPORTS AND SLIDE
BED ARE FULLY
ENGAGED WITHIN
CHANNEL OF SLIDE
RAILS.
SCREW PFH 8x2 1/2
(24 PLCS)
M78
EL
EK
