STEP 20
2 9/16
TYP
2 9/16
TYP
M44
M44
SCREW PFH 8x1 1/8
(24 PLCS)
SCREW PFH
8x1 1/8
(24)
1 13/16 TYP
M44 - PICKET - 42 - W4L07152
5/8"x3 3/8"x21 3/8" (16x86x542)
(6)
47
