STEP 21
SCREW PFH
8x1 1/8
(28)
M44 - PICKET - 42 - W4L07152
5/8"x3 3/8"x21 3/8" (16x86x542)
(7)
2 7/16
TYP
1 13/16 TYP
SCREW PFH 8x1 1/8
(28 PLCS)
M44
48
