Bad Boy 1022H Operator's Manual

6
-
19
MAINTENANCE
6
(2) High-capacity fuse
This tractor is equipped with three fuses
for wiring.
These fuses are blown to cut current to
the electric circuit in order to protect wir-
ing. Find the cause for blown fuses and
replace them with the specified genuine
parts.
<Inspection>
Check the fuse through the transpar-
ent window to see if it is blown.
If a lamp does not come on by oper-ating
the corresponding switch:
①
Check the corresponding fuse.
②
If the fuse is intact, remove the
bulb socket from the lamp.
③
Remove the bulb from the socket
and check for blown lament.
④
If the filament is blown, replace
the bulb with a new bulb with the
same capacity.
Bulb Specications
Headlamp 12V H8 35W
Turn signal lamp(Left) 12V 21W
Turn signal lamp(Right) 12V 21W
Position lamp 12V 21W
LAMP BULB
