OPERATION DESCRIPTION
4
(1) Range Shift Lever
(A) H igh (B) Low
RANGE SHIFT LEVER
The range gear is shifted in three
stages, in combination with the main
gear shifting. When shifting the range
gear, depress clutch fully.
PTO SHIFT LEVER
The revolution of the PTO shaft can
be shifted in two stages. (1st Rear
540 rpm : 2nd Rear 960 rpm - Mid
2500 rpm) When shifting level, press
clutch pedal deeply.
(1) PTO Shift Lever
CAUTION

Do not shift while driving.
[Otherwise] The gear may be
damaged.
CAUTION

Observe the PTO speed desig-
nated on the work unit.

Otherwise, the work unit may
be damaged and cause an ac-
cident.
