Specifications
5-
1
SPECIFICATION TABLE
Engine
Make
S
pecification
Type
1 cylinder, 4-cycle, gasoline, SOHC, liquid
cooled
Displacement cc
546CC for 550cc
735CC for 750cc
Horsepower Kw(HP)
20.2（27.1）for 550cc
28.8（38.6）for 750cc
Rated revolution rpm
5500 for 550cc
6000 for 750cc
Low idling revolution
rpm 1350 to 1500
Fuel Capacity L(U.S.gal)
28（7.4）
Transmission CVT
Wheels, Drive system 4, Rear 2WD or 4WD
Differential lock Electric control: switch
Gear selection H-L range forward, Neutral, Reverse
Brakes
Front/Rear Hydraulic disk brake
Parking brake Mechanical brake
Steering Electronic power
Dimensions
Length
2980 (117.32)
Wide mm (in.)
1550（61.02）
Height mm (in.)
1950（76.77）
Front tread centers mm (in.) 1300 (51.18)
Rear tread centers mm (in.) 1285 (50.59)
Wheelbase mm (in.)
1950（76.77）
Ground
Clearance
front axle
mm (in.)
310（12.2）
rear axle
310（12.2）
Turning diameter
m (ft.)
8.6（28.22）
Suspension
Front Independent, Dual A-arm type
Rear Independent, Dual A-arm type
Max. rolling weight (Towing Capacity) kg (lbs.)
544（1200）
Payload capacity kg (lbs.)
159（350）
Weight kg (lbs.)
743（1638）for 550cc
720（1587）for 750cc
mm (in.)
