INSTALLATION INSTRUCTIONS | LIBRA COLLECTION
INSTALLATION WITH ACCESS UNDER THE FLOOR
1
PLUMBING
PVC DRAIN
PVC & BRASS DRAIN
BRASS DRAIN
B-2B-2
B-1B-1
B-3B-3
B-4B-4
B-5B-5
Overow pipe
PVC Connector
PVC Drain
NOTE: If necessary, cut the overow pipe to
the desired length, and glue it to the
PVC connector and to the drain.
