Baja BA 250 - Initial Battery Charging Procedure; Connecting Battery Cables; Charging Rate and Time; Battery Installation After Charging

47
How to Initially Charge the battery:
1. Connect the red positive (+) cable to
the red positive (+) pole of the battery.
(see gure 24)
2. Connect the black negative (-) cable
to the black negative (-) pole of the
battery. (see gure 25)
Note: The red positive (+) cable has a
larger diameter than the black negative
y cable.
3. Charging rate: Charge battery @ 0.7
Amps for
5 ~ 10 hours.
• After charging is complete, install
securely all six battery caps (see
gure 26)
• Install battery into battery tray
located under seat (see gure 27).
• Once battery is rmly seated in
tray, attach red positive (+) wire
to positive (+) terminal on battery,
then attach black negative (-) wire to
negative (-) terminal on battery (see
gure 27)
Figure 25
Figure 27
Figure 24
Figure 26
INSPECTION AND MAINTENANCE
