Speedometer Details
7
1. Speedometer :
The Speedometer pointer shows the speed
of vehicle in Km/Hr.
2. Odometer : The Odometer shows the total
distance that the vehicle has travelled.
3. Neutral Indicator : When the transmission is
in Neutral and Ignition switch is ON, the
Neutral indicator will glow.
4. Hi Beam Indicator : When Headlight is ON
and Hi beam is selected with engine running,
Hi beam indicator will glow.
5. Turn Signal Indicator (LH & RH) :
When Turn signal switch is turned to Left or
Right, Turn pilot indicator will flash.
6. Fuel Level Indicator : : It shows approximate level
of fuel in fuel tank.
AHO Feature - AHO (Automatic Headlight ON)
feature is provided.
There is no ‘Light switch’ on RH control
switch.
Ignition switch ON Speedometer lamp
Engine OFF Tail lamp, Number
Plate Lamp, Pilot Lamp in
Headlamp will get ON
Ignition switch ON Headlamp will get
Engine Running ON as per Low/High
Beam selector switch
position.
: Hi Beam
: Low Beam
4
6
5
3
1
2
N
4
5
3
1
2
CT 100 ES / CT 110 CT 100 KS
