Removal of Side Covers

Removal of Side Cover LH & RH

• Insert the key into the cover lock (C) and

turn the key clockwise & pull the Side

cover LH out from the bottom.

• Pull Side cover from (A) to release Lug

provided on Side cover from hole

provided on Fuel Tank.

• Slide the Side Cover forward (towards the

engine) from location (B) to release slot

provided on rear side of Side cover from

bracket with rubber cap provided on

Frame. Take out Side cover.

CAUTION : Remove cover as described

above, otherwise the lugs may break.

• Similarly Side cover RH can be removed

after removing screw (D).

Side

Cover

Side

Cover
