Technical Specifications
Engine : 4 stroke, Single cylinder, Natural air
cooled, SI Engine.
Bore x Stroke : 53.0 mm x 45.0 mm
Eng. Displacement : 99.27 cc
Compression Ratio : 9.5 + 0.5 : 1
Idling Speed : 1300 + 150 rpm
Max. Net Power : 6.03kW (8.2Ps) at 7500 rpm
Ignition System : C.D.I.
Spark Plug : Mico UR3AC or Champion PRZ9HC
Spark Plug Gap : 0.6 to 0.7 mm
Lubrication : Wet sump, Forced.
Transmission : 4 speed constant mesh.
Front Brake : Mech. expanding shoe type.
Rear Brake : Mech. expanding shoe type.
Fuel Tank Capacity :
Full : 10.5 litres
Reserve : 2.4 Lit.
Un usable Reserve : 0.5 Lit.
Dimensions :
Length : 1970 mm for Round H.L.
: 1950 mm for Trapezoidal H.L.
Width : 770 mm
Height : 1065 mm
Wheel base : 1235 mm
Min. Turning radius : 1900 mm
Ground clearance : 150 mm (Min.)
Tyre Size
Front : 2.75-17
Rear : 3.00-17
Tyre Pressure
Front : 1.75 kg/cm2 (24.5 psi)
Rear (Solo) : 2.00 kg/cm2 (28 psi)
Rear (Pillion) : 2.50 kg/cm2 (36 psi)
Electrical System : 12 Volts AC + DC
Head Lamp : 35/35 W
Stop Lamp/Tail Lamp : 21 W / 5 W
Turn Signal Lamp : 10 W
Neutral Indicator Lamp : 3 W
Hi Beam Indicator Lamp : 3 W
Turn Pilot Indicator Lamp : 3 W
Speedometer Lamp : 3 W (2 Nos.)
Horn : 12 V DC
Battery : 12 V-2.5 Ah
Vehicle Kerb Weight : 109 kg.
Gross Vehicle Weight : 239 kg.
Max. Speed : 90 km/hr.
(With single rider 68 kg)
Climbing Ability : 25% (140) max.
Note : All dimensions are under UNLADEN condition. Above
information is subject to change.
2
Identification Data
The Frame and Engine serial numbers are used to register the motorcycle. They are the unique
alpha-numeric codes to identify your particular vehicle from others of the same model and type.
Engine Number Location
On LH Side Crankcase
Near Gear Change Lever
(Alpha-Numeric - 11 Digits)
Frame Number Location
On LH Side of Steering Tube
(Alpha-Numeric - 17 Digits)
