Technical Specifications
2
Engine : 4 stroke, Single Cylinder, Natural air
cooled.
Bore x Stroke : 58.00mm x 56.40mm
Engine Displacement : 149.01 cc
Compression Ratio : 9.5 + 0.5 : 1
Max. Net Power : 14.09 Ps at 8500 rpm
Max. Net Torque : 12.76 Nm at 6500rpm
Ignition System : Microprocessor controlled digital CDI
Spark Plug : Champion RG 4 HC. 2 Nos.
Spark Plug Gap : 0.6 to 0.8 mm
Lubrication : Wet sump, Forced.
Transmission : 5 speed constant mesh.
Front Brake : Hydraulic disc type.
Rear Brake : Mech. expanding shoe & drum type.
Fuel Tank Capacity :
Full : 15 litres
Reserve : 3.2 litres
Usable Reserve : 2 litres
Dimensions :
Length : 2055 mm
Width : 790 mm
Height : 1100 mm
Wheel base : 1320 mm
Min. Turning radius : 2320 mm (Min.)
Ground clearance : 165 mm (Min.)
Tyre Size
Front : 2.75 x 17, 41P
Rear : 100/90 x 17, 55P
Tyre Pressure
2
Front : 1.75 kg/cm (25 PSI)
2
Rear (Solo) : 2.00 kg/cm (28.5 PSI)
2
Rear (Pillion) : 2.25 kg/cm (32 PSI)
Electrical System : 12 Volts DC
Head Lamp : 35/35 W-HS1
Pilot Lamp : 5 W Each 2 Nos.
Tail /Stop Lamp : LED/LED
Turn Signal Lamp : 10 W 2Nos.
Neutral Indicator Lamp : LED
Hi Beam Indicator Lamp : LED
Turn Pilot Indicator Lamp : LED
Side Stand Indi. Lamp : LED
Speedometer Lamp : LED Display
Rear No. Plate Lamp : 5 W
Horn : 12 V DC
Battery : 12V - 7 Ah Dry
Vehicle Kerb Weight : 143 kg.
Gross Vehicle Weight : 273 kg.
0
Climbing Ability : 28% (16 max)
Note : All dimensions are under UNLADEN condition. Above
information is subject to change without any notice.
Identification Data
The Frame and Engine serial numbers are used to register the motorcycle. They are the unique
alpha-numeric codes to identify your particular vehicle from others of the same model and type.
Engine Number Location
On LH Side Crankcase
Near Gear Change Lever
(Alpha-Numeric - 11 Digits)
Frame Number Location
On LH Side of Steering Tube
(Alpha-Numeric - 17 Digits)
1
