HANDLEBAR ASSEMBLY
8. Using 4mm Allen wrench, remove 4 screws from bicycle stem.
10.After removing the front plate of the bicycle stem, insert center
of handlebars into bicycle stem, then reattach the front plate
and 4 screws to secure handlebars.
11. Make certain handlebars are positioned with the throttle to
the left and the rapid-fire index shifting levers on the right.
Slightly insert each of the 4 screws prior to tightening. Also
prior to tightening, rotate handlebars forward or backwards to
customize position of handlebars to rider. Note: In most cases,
brake levers should be angled approximately 45 degrees
downward for optimal positioning.
10. Display screen can be easily adjusted by loosening with a
3mm Allen wrench and rotating to desired position. To adjust
the display, you will need to loosen the screws on each side of
the display.
3.
For further assistance, go online for helpful instructional videos at bakcou.com
