Oil change
• Empty the tank of oil through the draining plug under the tank.
• Handle the waste oil according to law.
• Fill the tank to center line of the indicators in the dipstick of the filling cap.
• Oil tank volume: 32 litres.
• Recommended oil: Shell Tellus T46 or equivalent.
• Change hydraulic oil after the first 500 hours of operation and every 1000 hours thereafter.
• It is recommended to pump the oil into the tank through a 20 µ filter, because new oil in drums is not pure.
• If any oil has run out on the floor, wipe it away.
Filter change P20, P32
• Open the tank cover as shown in the figure below.
• Keep the cover open by using e.g. a block of wood.
• Unscrew the filter insert and remove it.
• Handle the old filter according to law.
• Lubricate the seal of the new filter insert with hydraulic oil.
• Screw the filter insert on.
• Filter insert must be changed together with oil.
