P20 / P32 OPERATIONS MANUAL

Page | 20

NO.

NAME

P20

P32

CODE

QTY

CODE

QTY

1

MASTER DIE SET

P-20140

8

P-32140

8

2

CONTROL DEVICE MS

P-20160

1

P-32160

1

3

ROTARY SWITCH

P-201601

1

P-321601

1

4

POSITION SPACER

P-201602

1

P-321602

1

5

SHAFT CLIP 7mm

P-201603

1

P-321603

1

6

CONTROL DEVICE BACKSTAND

P-201604

1

P-321604

1

7

BACKSTAND BEARING

P-201605

1

P-321605

1

8

COPPER BOLT

P-201606

1

P-321606

1

9

MOBILE DEVICE

P-201607

1

P-321607

1

10

SWITCH

P-201608

1

P-321608

1

11

CONTROL DEVICE FRONT PART

P-201609

1

P-321609

1

12

PIN

P-2016010

1

P-3216010

1

13

SPRING

P-2016011

1

P-3216011

1

14

SHAFT CLIP 8mm FOR PIN

P-2016012

1

P-3216012

1

15

CAPPED NUT

P-20141

8

P-32141

8

16

SCREW

P-20142

8

P-32142

8

17

SPRING

P-20143

8

P-32143

8

18

LOCKING PIN

P-20144

8

P-32144

8

19

ADAPTER SLEEVE M12-6L

P-20134

4

P-32134

4

20

CONIC FLANGE

P-20120

1

P-32120

1

21

PISTON

P-20150

1

P-32150

1

22

CYLINDER

P-20110

1

P-32110

1

23

PETURN CYLINDER

P-20130

2

P-32130

2

24

PISTON

P-20131

2

******

*

25

SEAL

P-20132

2

P-32132

2

26

SHELL NUT M12X1.5

P-20133

4

P-32133

4

27

SCREW M6X20

P-20113

4

P-32113

4

28

GUIDE RING P20-10XD220X2 / P32-20XD250X2

P-20151

1

P-32151

1

29

GUIDE RING P20-10XD160X2 / P32-10XD180X2

P-20111

1

P-32111

1

30

SCREW P20-M8X50 / P32-M12X50

P-20121

14

P-32121

14

31

PISTON ROD

P-20134

2

P-32134

2

32

GROOVED RING P20-UN160X180 / P32-UN180X200

P-20112

1

P-32112

1

33

SCREW

P-20135

4

*****

*

34

SPRING

P-20145

16

P-32145

16

35

SCREW OF PANEL SWAGE P20-M8X60 / P32-M12X60

P-20122

2

P-32122

2

36

GROOVED RING P20-UN200X220X15 / P32-UN230X250X15

P-20152

1

P-32152

1

37

ELBOW CONNECTOR

P-20136

2

P-32136

2

38

HYDRAULIC PIPE

P-20137

1

P-32137

1

39

HYDRAULIC PIPE

P-20138

1

P-32138

1
