P20 / P32 OPERATIONS MANUAL

Page | 22

O.

NAME

P20

P32

CODE

QTY

CODE

QTY

1

ELECTRIC MOTOR P20X3KW / P32X4KW

P-20201

1

P-32201

1

2

SCREW M14X55

P-20202

4

P-32202

4

3

AIR BREATHER

P-20203

1

P-32203

1

4

COUPLING

P-20301

1

P-32301

1

5

SCREW M6X10

P-20204

20

P-32204

20

6

COVER

P-20205

1

P-32205

1

7

MAGNET PLUG PT ½”

P-20401

1

P-32401

1

8

VALVE BLOCK

P-20206

1

P-32206

1

9

OIL ROUTE BLOCK

P-202061

P-322061

1

10

OVER FLOW VALVE

P-202062

P-322062

1

11

FLUID CONTROL ONE-WAY VALVE

P-202063

P-322063

1

12

PLUG G 1/8”

P-202064

P-322064

1

13

PRESSURE JOINTS M16X2 / G ¼”

P-202065

P-322065

1

14

PIP INTERFACE M12X6

P-202066

P-322066

1

15

PUMP P20X8L / P32X12L

P-20302

1

P-32302

1

16

SCREW 7/16”X14

P-20303

2

P-32303

2

17

O-RING NBR21x3.3

P-20207

1

P-32207

1

18

HYDRAULIC PIPE

P-20304

1

P-32304

1

19

SCREW M6X20

P-20305

4

P-32305

4

20

DIRECTIONAL VALVE 4/3

P-20208

1

P-32208

1

21

FLANGE B5

P-20209

1

P-32209

1

22

RIVET NUT M6

P-20210

20

P-32210

20

23

HYDRAULIC PIPE F12X2

P-20306

1

P-32306

1

24

PLUG

P-20211

1

P-32211

1

25

SPRING WASHER 7/16”

P-20307

2

P-32307

2

26

SPRING WASHER

P-20308

4

P-32308

4

27

NIPPLE 12S

P-20309

1

P-32309

1

28

FILTER INSERT ¾”

P-20310

1

P-32310

1

29

UNDER-CHASSIS

P-20402

4

P-32402

4

30

MALE STUD COUPLING 12S / G1/4”

P-20311

1

P-32311

1

31

USIT-RING

P-20312

1

P-32312

1
