Page #25 background image
www.balluff.com 11english
The specifications are typical values for 24VDC at room
temperature.
Further data can be found at www.balluff.com
on the product page.
8.1 General features
Light type Red light
Wave length 660nm
8.2 Ambient conditions
Ambient temperature −25…+55°C
Storage temperature −40…+70°C
Relative humidity 35…85%
Protection per IEC60529
(when threaded together)
IP67
8.3 Detection range/Measuring range
Range ≤ 20m
8.4 Electrical data
Operating voltage 10...30VDC
Current draw ≤20mA
Load voltage ≤30VDC
Load current ≤100mA
Voltage drop
Load current ≤10mA ≤1.2V
Load current ≤100mA ≤2V
Switching frequency 1000Hz
Response time ≤ 0.5ms
Short-circuit protection yes
Protection against miswiring yes
Polarity reversal protected yes
Interference protection yes
8.5 Electrical connection
Connection
BOS R090K- _ U-RX10-S49/
BOS R090K- _ U-RX10-S75
Plug M8x1
BOS R090K- _ U-RX10-02 Cable, 2m, Ø3.5mm
8.6 Output / Interface
Open-Collector-Output
BOS R090K-PU-… PNP
BOS R090K-NU-… NPN
NC contact/NO contact Configurable
8.7 Materials
Housing material PBT
Lens PMMA
Display PC
8.8 Mechanical features
Installation 2× screw M3
Dimensions (W × H × L) See Fig. 4-1 on
page7
8
Technical data
BOS R090K-_U-RX10-S49/S75/02
Optoelectronic sensors – Through-beam sensors
