B&G universal interface box - Page 25

installation
53mm
ORIENTATION
48mm
113.1mm
BGM014062
BOX BASE OUTLINE
Drill 4 off holes
(2.9mmØ)for
No.6 x 3/4" self
tapping screws
Utiliser le
gabarit les
instructions
fournis
pour
monter le
module
Interface.
