B&G universal interface box - Installation

installation
53mm
ORIENTATION
48mm
113.1mm
BGM014062
BOX BASE OUTLINE
Drill 4 off holes
(2.9mmØ)for
No.6 x 3/4" self
tapping screws
WARNING: THIS DRAWING IS NOT TO SCALE
Use the Installation instructions and the template provided with the unit packaging to install the Interface Box.
