Power rating: 8 ohms 125 watts @ 1 kHz
4 ohms 185 watts @ 1 kHz
Frequency response 5 Hz - 45 kHz
Input sensitivity 1.0 Volts
THD (S+N) 0.09 % @ 1 kHz
Input impedance 33.2 k ohms
Damping factor 150
Current (peak to peak) 30 Amps
Slew rate 14 V / )sec
Dynamic headroom 1.4 dB
S/N (A-weighted) 95 dB
Voltage gain 28
Line voltage 120/220/240 VAC switchable
Dimensions (O.A.) 17"(w) X 16"(d) X 5.75"(h)
Weight 43 lb
Power consumption 1220 watts max
12.2 Amps max current draw
125 watts @ no input
Replacement fuses Line -12 Amp/250 Volt Slow Blow
Rails - 4 Amp/250 Volt Slow Blow
