27
PREAMPLIFIER TUNER SPECIFICATIONS
Preamplifier
Specifications
Miscellaneous
Frequency Response:
5 - 20 kHz, +0
/
0.5dB
Line voltage: 120/220/240 VAC
Input Sensitivity: 63 mV Power consumption: 30 watts max
Maximum Output Level: 8 V rms Replacement fuses: Line 0.5 Amp/250 Volt
Signal to Noise Ratio: 89 dB A Weighted Dimensions: 17"(w) x 10"(d) x 3.50"(h)
Input Impedance: 50 k Ohms Weight: 10 pounds
Output Impedance: 221 Ohms
Audio Analog Inputs 6 Warranty:
See Warranty
5 years preamplifier
1 year remote
Audio Analog Outputs 4
High Pass Crossover 80 Hz 12 dB per octave Upgrade: RS232 software
Low Pass Crossover 80 Hz 12 dB per octave
Tuner Specifications FM Section Tuner Specifications AM section
Frequency Range: 87.5 - 107.9 MHz Frequency Range: 520 - 1670 kHz
Total Harmonic Distortion: Less than 0.25% Total Harmonic Distortion: Less than 0.3%
Frequency Response 20 - 15 kHz, +1/ -3 dB
Capture Ratio: 2 dB
IHF (Usable) Sensitivity: 12 dBf IHF (Usable) Sensitivity: 28 dBf
Mono/Stereo Sensitivity: 15 / 35 dBf
Alternate Channel
Selectivity:
65 dB Alternate Channel
Selectivity:
30 dB
Signal to Noise Ratio: 70 dB, A Weighted
Antenna Input Impedance: 75 Ohms Antenna Input Impedance: 300 Ohms
Specifications subject to change without notice
