REAR PANEL ENLARGED VIEW
TUNER
FM antenna
AM antenna
SERIAL NUMBER
Audio/Video Systems made in the U.S.A.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
www.bkcomp.com
V1
V2TV
SOURCE INPUTS
DVDCDINPUTOUTPUT
TAPE
PREAMP OUTPUTS
MONO
L+R
CONTROL
OUT
ACCESSORY CONNECTION
12VDC
50mA
+
COMPLIES WITH THE LIMITS
FOR A CLASS B COMPUTING
DEVICE PURSUANT TO
SUBPART J OF PART 15
AC IN
B&K Components, Ltd.
2100 Old Union Rd.
Buffalo, NY 14227
www.bkcomp.com
RS-232
HIGH
PASS
FULL
RANGE
6-12VDC
38kHz
