Pb (lead-acid) battery program
Charging Pb battery
'>3 seconds'
present
voltage of
the battery
charge
current
charged
capacity
operated
time
This is programmed for charging Pb (lead-acid) battery with nominal voltage from 2 to 40V. Pb
batteries are totally different from NiCd or NiMH batteries. They can only deliver relatively lower
current compare to their capacity, and similar restrictions definitely apply to charge. So the optimal
charge current will be 1/10 of the capacity. Pb batteries must not be charged rapidly. Always follow
the instruction is supplied by the manufacturer of battery.
When you are willing to alter the parameter value in the program, press key to make it blink
then change the value with or key. The value will be stored by pressing key once
again.
Display
Program Select
Pb Batt
Set up the charge current on the left and the nominal
voltage of the battery on the right. The charge current
ranges from 0.1 to 9.9A and the voltage should be one
of 6, 12 and 40V.
Start the charge process by pressing key for more
than 3 seconds.
The screen displays the state of charging process. To
stop charging forcibly, press key once.
The audible sound indicates you the end of process.
◀
Batt type
Stop
DEC
◀
INC
▶
Start/
Enter
DEC
◀
INC
▶
DEC
◀
INC
▶
Start
Enter
Start
Enter
Batt type
Stop
Start
Enter
