CONVEYOR
ITEM PART NUMBER QTY DESCRIPTION 600HD
1 504F-1 714 TINE
2 516A 14 RETAINING BAR A TO IDENTIFY NOTE HOLE AND DIVOT SPACING
3 516B 14 RETAINING BAR B TO IDENTIFY NOTE HOLE AND DIVOT SPACING
4 512A 14
BACKING STRIP A (IDENTIFIED BY MATCHING HOLE PATTERN TO RETAINING BAR A)
5 512B 14
BACKING STRIP B (IDENTIFIED BY MATCHING HOLE PATTERN TO RETAINING BAR B)
6 510 28 CHANNEL
7 504J 378 CAPSCREW
8 504M 56 WASHER
9 504N 378 WASHER, SPACER, NYLON, BLACK
10 504K 378 ANCHOR NUT
11 504G 56 CAPSCREW
12 504H 56 LOCKNUT
13 504A 1 BELT
14 504DK 1 OFFSET CHAIN, COMPLETE (BOTH SIDES)
15 504DKSL OFFSET CHAIN SEGMENT, LEFT SIDE
16 504DKSR OFFSET CHAIN SEGMENT, RIGHT SIDE
17 404DB CHAIN PIN WITH COTTER PIN
18 A504S CONVEYOR ASSEMBLY COMPLETE (NOT SHOWN)
19 504P 114 WASHER, SPACER, STEEL, GOLD
20 509H 378 LOCKWASHER
6-2b
61780 0221
