BUCKET AND CHAIN
3 CUBIC YARD HOPPER
*ONLY USE BARBER CHAIN AND LINKS!
20,000 LB MINIMUM TENSILE!
CORROSION PROTECTED ON CHAIN AND PINS
SUBSTITUTE CHAINS ARE A SAFETY HAZARD!
ITEM PART NUMBER QTY DESCRIPTION 600HDS
1 524M 1 LIFT ARM ASSEMBLY
2 225CM02 2 BEARING
3 560B10300 4 CAPSCREW
4 560FW10 8 FLAT WASHER
5 560LW10 4 LOCK WASHER
6 560N10 4 HEX NUT
7 525ZPA 2 TURNBUCKLE
8 525ZPB 2
CHAIN* SEE BELOW
9 525ZPC 2
CHAIN* SEE BELOW
10 503NN-4 4
CONNECTING LINK* SEE BELOW
11 525ZP 2
CHAIN ASSEMBLY* (ONE SIDE) SEE BELOW
12 525AS01 1 BUCKET
13 503NN-4PF 4 CONNECTING LINK* SEE BELOW
61780 0221
