Barber SURF RAKE 600HD - Drive Mechanism

61780 0221
DRIVE MECHANISM
ITEM PART NUMBER QTY DESCRIPTION 600HDS
1 503KK 6 RETAINING RING
2 503JJ 2 BEARING
3 503LL 2 GREASE FITTING
4 503AA 2 SPROCKET
5 503CAP 12 GREASE COVER
6 536 1 SHAFT
7 503J 2 KEY
8 595AS01 1 SPROCKET AND SHAFT ASSEMBLY
9 509H 20 LOCK WASHER
10 560B06250 16 CAPSCREW
11 549AS08 4 SEE IDLER ROLLER ASSEMBLY PAGE
12 540G 2 TAKE UP BOLT
13 503VV 2 BEARING
14 503AS01 2 GREASE LINE ASSEMBLY
15 560N12S 2 JAMB NUT
16 560B06100 4 CAPSCREW
17 549AS10A 4 SEE ROLLER ASSEMBLY PAGE
18 508CM01 2 BEARING COVER
19 549AS20 2 TOP IDLER ROLLERS
6
-
4
