MOLDBOARD & SHIELDS
ITEM PART NUMBER QTY DESCRIPTION 600HD SOLID BELT HYDRAULIC (OPTION)
1 542BU05 2 TAKE UP GUARD
2 560B05125 2 CAPSCREW
3 509D 2 BOLT
4 509C 6 FLAT WASHER
5 509FA 2 LOCK NUT
6 522AS02 1 MOLDBOARD
7 541 2 SKID SHOE
8 524D 4 CAPSCREW
9 524G 4 LOCK WASHER
10 523R 4 HEX NUT
11 542AS01 (R/L) 2 SIDE GUARD
12 514D 6 CAPSCREW
13 509H 6 LOCK WASHER
14 509J 6 HEX NUT
15 518AA 2 WINGNUT
16 543AS04 (R/L) 2 SIDE GUARD (LEFT SHOWN)
17 524X 16 CAPSCREW
18 560B04175 4 CAPSCREW
19 560B08100 4 CAPSCREW
20 560LA01 4 SPRING LATCH ASSEMBLY
21 560N05L 18 HEX NUT
22 522F 1 MOLDBOARD FLAP
23 524S 18 FLAT WASHER
24 603GG 6 FLAT WASHER
25 542EB 1 LOWER TOP SHIELD ASSEMBLY
26 542EA 1 UPPER TOP SHIELD ASSEMBLY
27 560N08L 4 LOCKNUT
28 560B04450 2 CAPSCREW
29 560N04L 8 HEX NUT
30 542DA 2 STONE GUARD FLAP
31 542DB 2 STONE GUARD FLAP HOLD DOWN
32 514G 4 FLAT WASHER
33 522G 1 MOLDBOARD FLAP HOLD DOWN
61780 0221
